Pur Hot Melt MDF Wood Profile Wrapping Machines for Aluminum/ Wpc /upvc /pvc
Product Details:
| Place of Origin: | China |
| Brand Name: | Easwon |
| Certification: | CE |
| Model Number: | PUR450 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiated |
| Packaging Details: | wooden case |
| Delivery Time: | 25 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50 set per month |
|
Detail Information |
|||
| Model No.: | PUR450 | Total Power: | 10kw |
|---|---|---|---|
| Heating Power: | 7kw | Working Speed: | 0-50m/min |
| Profile Width: | 40-450mm | Max. Profile Thickness: | 125mm |
| Max. Foil Diameter: | 400mm | Max. Foil Width: | 450mm |
| Condition: | New | Warranty: | 1 Year |
Product Description
Pur Hot Melt MDF Wood Profile Wrapping Machines for Aluminum/ Wpc /upvc /pvc
Materials for PUR profile wrapping machine:
Glue type: PUR hot melt glue
Substrate profiles: WPC, UPVC, Aluminum, MDF, PVC, plywood, solid wood etc.
Surface materials: roll PVC foil, veneer, CPL, leather, aluminum foil, PP etc
Application of PUR profile wrapping machine:
PUR profile wrapping machine is suitable for professional furniture and acoustic manufacturer with Rolling material on different panels and Suitable for building materials ,furniture ,tabletops ,doors ,windows,skirting line, ceiling, trim or related manufactuers use.Complex shapes can achieve the perfect product surface cladding process.
Specification:
| Model no. | PUR450 |
| Overall dimension | 6000x750x2200mm |
| Weight | 2500kg |
| Total power | 10kw |
| Conveyor power | 1.5kw |
| Dusting motor power | 0.37kw x 3 |
| Heating power | 7kw |
| Pneumatic load | 6 bar |
| Working speed | 0-50m/min |
| Profile specification |
Width: min 40mm, up to 450mm Thickness: up to 125mm Length: min. 400mm |
| Foil type | PVC, veneer, PP, PET, Alu., paper etc |
| Foil specification |
Core diameter: 3in. Foil diameter: up to 400mm Foil width: up to 450mm |
| Glue melt |
Barrel type Pail: 20 liter or 5 gallon Pail diameter: 280mm Melt capacity: 20kg/hr Number of hoses: 1 Temperature control sensor: PT100 Glue type: PUR |
| Control system | PLC with 10in full color touch screen |
Package and shipping:
We will take care of your machinery packages well like picture show.
Our workers will make sure your machine clean before package.
We will add stretchy film for the whole machine and spare parts for delicate protection.
We will make export standard strong Wooden box case package as your request.
|
|
Guarantee:
The machine is guaranteed for 12 months .Within 12 months under normal using and maintenance, if the machine has something problem ,you will get spare part for free . More than 12 months,you will get the cost price for accessories. You will also get technical support and service all the time.
Technical support:
Technical support by Phone, Email, Wechat, WhatsApp and Skype, 24 hours online.
We provide English version manual and Operational video.
Engineer available to service machinery overseas.
After sales services:
Our machine is installed and tested well before delivery. You can operate the machine immediately after receiving machine.
If you don't know how to use the machine, we will offer you free training until you can use machine freely. And If there is still have any question, please contact us by Email, Skype, Wechat, WhatsApp, Phone and Trade Manager online service at any time.
