Tractor Mounted Garlic Planter 180mm 9 Rows 20 - 50hp Matched Power
Product Details:
| Place of Origin: | China |
| Brand Name: | Easwon |
| Certification: | CE, ISO |
| Model Number: | 1ZY-9 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiated |
| Packaging Details: | steel frame or wooden case |
| Delivery Time: | 15-20 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 500 sets per month |
|
Detail Information |
|||
| Matched Power: | 20-50hp | Rows: | 9 Rows |
|---|---|---|---|
| Row Space: | 180mm | Planting Space: | 100-280mm Adjustable |
| Use: | Planting Garlic | Planting Depth: | 0-40mm |
| Model: | Tractor-mounted Garlic Planter | Condition: | New |
| Warranty: | 1 Year | After-sales Service: | Free Spare Parts, Video Technical Support, Online Support |
| High Light: | 9 Rows Garlic Planter,180mm Garlic Planter Machine,Tractor Mounted Garlic Seeding Machine |
||
Product Description
Garlic planter can be 3 - 10 rows, the row space is fixed and 180mm, Row space is adjustable from 100mm to 280mm. It can match the tractor of 20-50hp. It is widely used in plains and hills to realize the mechanization planting of garlic. Through the adjustment of the garlic head, it can realize the continuous spot planting. The garlic planter adopts the technique of on-demand and conical spiral guide tube. The size of the cone hole can ensure that the scale bud of the garlic clove does not tilt upwards. The size of the conical spiral guide tube determines the rate of the buds of the garlic clove. The structural size and center of gravity of the garlic cloves are about one-third of the total length of the roots. The faster the falling speed and the spin speed of the garlic cloves in the conical spiral guide tube, the higher the rate of scaly buds entering the soil. It can do the work of ridging, planting, mulch cover soil etc.
Technical indicators:
1. Planting uniform coefficient of each line%: ≤3.8;
2. Total row seeding stability coefficient of variation%: ≤ 1.2;
3. One turnaround success rate%: ≥92%;
4. Point depth qualification rate%: ≥90%;
5. The whole machine travels linear offset: ≤50mm;
6. Virtual feeding times: ≤ 50 times/h;
7. Vibration causes the surface garlic to jump height: ≤10mm
Technical specification
| Model | 1ZY-9 | |
| Fitted power | HP | 20-50 |
| Rows | 9 | |
| Row space | mm |
180mm(fixed) |
| Plant space | mm | 100-280 adjustable |
| Planting depth | mm | 0-40 |
| Overall dimension | mm |
1700x1500x1050 |
| Weight | kg | 286 |
 |
|
|
|
Package&Shipping:
|
The normal package is iron box, If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request |
After sales services:
1. Warranty: 1 year
2. Lifetime upgrades and consulting services
3. 24-hour servic hot line for consulting and solving the problems
4. Provide product design and solution within 24 hours
